Features

Structural & mechanical specifications:

- Frame construction: Fabricated ERW tubes (conforming to IS: 3074-2005) with high-strength steel channels (IS: 513/IS: 2062/1079)
- Welding: Industrial-grade MIG welding for maximum load-bearing capacity
- Surface treatment: 7-tank pre-treatment process followed by anti-corrosive black powder coating

Safety features (Seatbelt):

- Type: 3-Point ELR (Emergency Locking Retractor) integrated seatbelt
- Buckle: Mounted on the seat frame to ensure the belt moves with the driver during suspension travel
- Certification: IS-15140: 2018 (Indian Standard) for seat strength and anchorage

Optional sensor technology:

- Occupancy sensor: Detects driver presence to activate/deactivate instrument cluster warnings

Adjustability:

- Fore/Aft movement: 150 mm total travel in 10-15 mm increments
- Height adjustment: Independent front and rear height adjustment (up to 60 mm)
- Reclining: Continuous or stepped adjustment (backrest angle from 90° to 120°)

Material upholstery:

- Fire-retardant (FR) PVC Leather or heavy-duty Automotive Fabric (breathable)
